更多>>FNQ系列1.8V晶體時鐘振蕩器,FNETHE025
來源：http://www.ntlitai.cn 作者：康華爾電子 2022年07月27
我們的汽車兼容石英晶體振蕩器 (XO) 旨在滿足汽車應用的嚴格要求，并在其部件號中以“Q”區分。它們是在經過嚴格 IATF 16949 標準認證的設施中制造的，并且能夠根據 VDA6.3 進行客戶審核。這些零件均受 PPAP（生產零件批準流程）文檔支持，從而滿足汽車電子行業的所有要求。此外，所有符合汽車標準的晶體振蕩器 (XO) 均已使用 AECQ-200 和 QAP-81 進行了認證，以涵蓋石英諧振器和 XO IC，而不是使用 AEC-Q100（僅針對 IC 定義）。我們計劃在 2021 年開始為我們新的符合汽車標準的XO產品逐步采用 AECQ-104 認證標準，汽車電子晶振，但它不會將之前符合 AECQ-200 + QAP-81 的產品重新認證為 AEC-Q104（AECQ- 200 + QAP-81 資格標準和 AECQ-0104 資格標準是測試數量和添加 X 射線檢查）
FNQ系列1.8V晶體時鐘振蕩器,FNETHE025,FN1000064,7050mm晶振,時鐘晶體振蕩器
亞陶晶振FNQ系列1.8V時鐘晶體振蕩器可在廣泛的工作條件和頻率范圍內實現出色的抖動和穩定性。使用非PLL振蕩器設計在內部生成的輸出時鐘信號與LVCMOS/LVTTL邏輯電平兼容。該器件采用卷帶包裝，采用7.0 x 5.0mm表面貼裝陶瓷封裝。FNQ系列是需要低抖動和低功耗的汽車應用的理想參考時鐘
| KK3270052 | Diodes Incorporated | SaRonix-eCera™ KK | 32.768kHz | ±25ppm |
| KK3270052 | Diodes Incorporated | SaRonix-eCera™ KK | 32.768kHz | ±25ppm |
| KK3270052 | Diodes Incorporated | SaRonix-eCera™ KK | 32.768kHz | ±25ppm |
| JX7011B0044.736000 | Diodes Incorporated | SaRonix-eCera™ JX | 44.736MHz | ±25ppm |
| JX7011B0044.736000 | Diodes Incorporated | SaRonix-eCera™ JX | 44.736MHz | ±25ppm |
| JX7011B0044.736000 | Diodes Incorporated | SaRonix-eCera™ JX | 44.736MHz | ±25ppm |
| KK3270051 | Diodes Incorporated | SaRonix-eCera™ KK | 32.768kHz | ±25ppm |
| KK3270051 | Diodes Incorporated | SaRonix-eCera™ KK | 32.768kHz | ±25ppm |
| KK3270051 | Diodes Incorporated | SaRonix-eCera™ KK | 32.768kHz | ±25ppm |
| JX5011C0120.000000 | Diodes Incorporated | SaRonix-eCera™ JX | 120MHz | ±50ppm |
| JX5011C0120.000000 | Diodes Incorporated | SaRonix-eCera™ JX | 120MHz | ±50ppm |
| JX5011C0120.000000 | Diodes Incorporated | SaRonix-eCera™ JX | 120MHz | ±50ppm |
| KX2132709Z | Diodes Incorporated | SaRonix-eCera™ KX | 32.768kHz | ±25ppm |
| KX2132709Z | Diodes Incorporated | SaRonix-eCera™ KX | 32.768kHz | ±25ppm |
| KX2132709Z | Diodes Incorporated | SaRonix-eCera™ KX | 32.768kHz | ±25ppm |
| JX7012D0025.001875 | Diodes Incorporated | SaRonix-eCera™ JX | 25.001875MHz | ±25ppm |
| JX7012D0025.001875 | Diodes Incorporated | SaRonix-eCera™ JX | 25.001875MHz | ±25ppm |
| JX7012D0025.001875 | Diodes Incorporated | SaRonix-eCera™ JX | 25.001875MHz | ±25ppm |
| JX7011E0091.500000 | Diodes Incorporated | SaRonix-eCera™ JX | 91.5MHz | ±50ppm |
| JX7011E0091.500000 | Diodes Incorporated | SaRonix-eCera™ JX | 91.5MHz | ±50ppm |
| JX7011E0091.500000 | Diodes Incorporated | SaRonix-eCera™ JX | 91.5MHz | ±50ppm |
| KJ3270004Z | Diodes Incorporated | SaRonix-eCera™ KJ | 32.768kHz | ±50ppm |
| KJ3270004Z | Diodes Incorporated | SaRonix-eCera™ KJ | 32.768kHz | ±50ppm |
| KJ3270004Z | Diodes Incorporated | SaRonix-eCera™ KJ | 32.768kHz | ±50ppm |
| PD10GE159 | Diodes Incorporated | SaRonix-eCera™ ASSP XO™ | 159.375MHz | ±50ppm |
產品特點
符合AEC-Q200標準
頻率范圍：1至156.25MHz有源晶振
<1 ps RMS 抖動
1.8V CMOS/TTL 兼容邏輯電平
與標準 7.0 x 5.0mm 封裝引腳兼容
專為標準回流和清洗技術而設計
低功耗待機模式
無鉛且符合 RoHS/Green 標準
應用：信息娛樂系統， 主機
FNQ系列1.8V晶體時鐘振蕩器,FNETHE025,FN1000064,7050mm晶振,時鐘晶體振蕩器| PD10GE159 | Diodes Incorporated | SaRonix-eCera™ ASSP XO™ | 159.375MHz | ±50ppm |
| PD10GE159 | Diodes Incorporated | SaRonix-eCera™ ASSP XO™ | 159.375MHz | ±50ppm |
| PDGPON155 | Diodes Incorporated | SaRonix-eCera™ ASSP XO™ | 155.52MHz | ±50ppm |
| PDGPON155 | Diodes Incorporated | SaRonix-eCera™ ASSP XO™ | 155.52MHz | ±50ppm |
| PDGPON155 | Diodes Incorporated | SaRonix-eCera™ ASSP XO™ | 155.52MHz | ±50ppm |
| JX7011D0104.000000 | Diodes Incorporated | SaRonix-eCera™ JX | 104MHz | ±25ppm |
| JX7011D0104.000000 | Diodes Incorporated | SaRonix-eCera™ JX | 104MHz | ±25ppm |
| JX7011D0104.000000 | Diodes Incorporated | SaRonix-eCera™ JX | 104MHz | ±25ppm |
| JT255BI0032.000000 | Diodes Incorporated | SaRonix-eCera™ JT | 32MHz | ±2ppm |
| JT255BI0032.000000 | Diodes Incorporated | SaRonix-eCera™ JT | 32MHz | ±2ppm |
| JT255BI0032.000000 | Diodes Incorporated | SaRonix-eCera™ JT | 32MHz | ±2ppm |
| LDA000004 | Diodes Incorporated | SaRonix-eCera™ LD | 100MHz | ±50ppm |
| FN2500246 | Diodes Incorporated | SaRonix-eCera™ FN | 25MHz | ±50ppm |
| FN2500246 | Diodes Incorporated | SaRonix-eCera™ FN | 25MHz | ±50ppm |
| FN2500246 | Diodes Incorporated | SaRonix-eCera™ FN | 25MHz | ±50ppm |
| FN1000064 | Diodes Incorporated | SaRonix-eCera™ FN | 10MHz | ±50ppm |
| FN1000064 | Diodes Incorporated | SaRonix-eCera™ FN | 10MHz | ±50ppm |
| FN1000064 | Diodes Incorporated | SaRonix-eCera™ FN | 10MHz | ±50ppm |
| UJ2600001 | Diodes Incorporated | SaRonix-eCera™ UJ | 26MHz | ±20ppm |
| UJ2600001 | Diodes Incorporated | SaRonix-eCera™ UJ | 26MHz | ±20ppm |
| UJ2600001 | Diodes Incorporated | SaRonix-eCera™ UJ | 26MHz | ±20ppm |
| FN7500043 | Diodes Incorporated | SaRonix-eCera™ FN | 75MHz | ±25ppm |
| FN7500043 | Diodes Incorporated | SaRonix-eCera™ FN | 75MHz | ±25ppm |
| FN7500043 | Diodes Incorporated | SaRonix-eCera™ FN | 75MHz | ±25ppm |
| FNSTB1027 | Diodes Incorporated | SaRonix-eCera™ ASSP XO™ | 27MHz | ±30ppm |
FNQ系列1.8V晶體時鐘振蕩器,FNETHE025,FN1000064,7050mm晶振,時鐘晶體振蕩器
| 類別 | XO振蕩器 |
|---|---|
| 產品系列 | FNQ |
| 合規性（僅汽車支持 PPAP） | 汽車級晶振 |
| 頻率范圍 (MHz) | 1 到 135 |
| 抖動均方根 (ps) | <1 |
| 穩定性 (PPM) | 20 到 50 |
| 包裝尺寸（毫米） | 7.0 x 5.0 |
| 包裝類型 | 陶瓷縫 |
| 輸出邏輯 | CMOS |
| 電源電壓 (V) | 1.8 |
| 墊 | 4 |
| FNSTB1027 | Diodes Incorporated | SaRonix-eCera™ ASSP XO™ | 27MHz | ±30ppm |
| FNSTB1027 | Diodes Incorporated | SaRonix-eCera™ ASSP XO™ | 27MHz | ±30ppm |
| FNSURV054 | Diodes Incorporated | SaRonix-eCera™ ASSP XO™ | 54MHz | ±30ppm |
| FNSURV054 | Diodes Incorporated | SaRonix-eCera™ ASSP XO™ | 54MHz | ±30ppm |
| FNSURV054 | Diodes Incorporated | SaRonix-eCera™ ASSP XO™ | 54MHz | ±30ppm |
| FDSAS6062 | Diodes Incorporated | SaRonix-eCera™ ASSP XO™ | 62.5MHz | ±50ppm |
| FDSAS6062 | Diodes Incorporated | SaRonix-eCera™ ASSP XO™ | 62.5MHz | ±50ppm |
| FDSAS6062 | Diodes Incorporated | SaRonix-eCera™ ASSP XO™ | 62.5MHz | ±50ppm |
| FN5000121 | Diodes Incorporated | SaRonix-eCera™ FN | 50MHz | ±50ppm |
| FN5000121 | Diodes Incorporated | SaRonix-eCera™ FN | 50MHz | ±50ppm |
| FN5000121 | Diodes Incorporated | SaRonix-eCera™ FN | 50MHz | ±50ppm |
| FD2450017 | Diodes Incorporated | SaRonix-eCera™ FD | 24.576MHz | ±50ppm |
| FD2450017 | Diodes Incorporated | SaRonix-eCera™ FD | 24.576MHz | ±50ppm |
| FD2450017 | Diodes Incorporated | SaRonix-eCera™ FD | 24.576MHz | ±50ppm |
| FN2500140 | Diodes Incorporated | SaRonix-eCera™ FN | 25.000625MHz | ±25ppm |
| FN2500140 | Diodes Incorporated | SaRonix-eCera™ FN | 25.000625MHz | ±25ppm |
| FN2500140 | Diodes Incorporated | SaRonix-eCera™ FN | 25.000625MHz | ±25ppm |
| FN4800068 | Diodes Incorporated | SaRonix-eCera™ FN | 48MHz | ±50ppm |
| FN4800068 | Diodes Incorporated | SaRonix-eCera™ FN | 48MHz | ±50ppm |
| FN4800068 | Diodes Incorporated | SaRonix-eCera™ FN | 48MHz | ±50ppm |
| FN3330078 | Diodes Incorporated | SaRonix-eCera™ FN | 33.333MHz | ±30ppm |
| FN3330078 | Diodes Incorporated | SaRonix-eCera™ FN | 33.333MHz | ±30ppm |
| FN3330078 | Diodes Incorporated | SaRonix-eCera™ FN | 33.333MHz | ±30ppm |
| FN0200045 | Diodes Incorporated | SaRonix-eCera™ FN | 2.048MHz | ±50ppm |
| FN0200045 | Diodes Incorporated | SaRonix-eCera™ FN | 2.048MHz | ±50ppm |
| FKQ 1.8V | 20~50 | 3.2 x 2.5 | CMOS | 1.8 | 4 | 1.8V、3.2x2.5mm、汽車級CMOS晶體振蕩器 | |
|---|---|---|---|---|---|---|---|
| FKQ 2.5V | 20~50 | 3.2 x 2.5 | CMOS | 2.5 | 4 | 2.5V、3.2x2.5mm、汽車級晶振CMOS晶體振蕩器 | |
| FKQ 3.3V | 20~50 | 3.2 x 2.5 | CMOS | 3.3 | 4 | 3.3V、3.2x2.5mm、汽車級CMOS晶體振蕩器 | |
| FNQ 1.8V | 20~50 | 7.0 x 5.0 | CMOS | 1.8 | 4 | 1.8V、7.0x5.0mm、汽車級CMOS晶體振蕩器 | |
| FNQ 2.5V | 20~50 | 7.0 x 5.0 | CMOS | 2.5 | 4 | 2.5V、7.0x5.0mm、汽車級CMOS晶體振蕩器 | |
| FNQ 3.3V | 20~50 | 7.0 x 5.0 | CMOS | 3.3 | 4 | 3.3V、7.0x5.0mm、汽車級CMOS晶體振蕩器 |
