高性能的泰藝溫補晶體振蕩器TXETDCSANF-20.000000最適合全球定位系統，Taitien, a leading supplier of frequency control solutions, has introduced the highly cost-effective disciplined crystal oscillator GT-11. The newly launched GT-11 provides a built-in GPS receiver module, which uses GPS or 1 pps as a disciplining signal. By disciplining and locking, GT-11 can achieve the accuracy and stability as an atomic clock with phase error controlled within 75 ns (RMS). Furthermore, GT-11 offers the advantages of small size and low power consumption.
GT-11’s excellent accuracy and stability performance allows it to replace rubidium clocks as a standard clock reference source. This series is particularly suitable for various laboratory instruments. The miniature size of 25.4 x 25.4 x 9.4 mm can provide more flexibility for customer’s product design space.
Key features:
Built-in GPS receiver module which provides +5.0 V for active antenna
Low power consumption (less than 0.6 W) for high-performance TCXO
Exceptional price and performance compared with traditional GPS OCXO reference solutions
10 MHz CMOS output and 1 pps CMOS output
Disciplined by external 1 pps input
Disciplined phase accuracy reaching 75 ns RMS
GPS NMEA output

Application:
Low-cost reference clock
Test and measurement equipment

高性能的泰藝溫補晶體振蕩器TXETDCSANF-20.000000最適合全球定位系統，頻率控制解決方案的領先供應商泰藝推出了極具成本效益的紀律晶體振蕩器GT-11。新推出的GT-11提供內置GPS接收模塊，和TCXO溫補晶振有源晶振TXETDCSANF-20.000000同樣得到廣大用戶的支持，使用GPS或1 pps作為紀律信號。GT-11通過紀律和鎖定，可以達到原子鐘的精度和穩定性，相位誤差控制在75納秒（RMS）以內。此外，GT-11 還具有體積小、功耗低的優點。
臺灣泰藝晶體GT-11卓越的精度和穩定性性能使其能夠替代銣時鐘作為標準時鐘參考源。該系列特別適用于各種實驗室儀器。25.4 x 25.4 x 9.4 mm的微型尺寸可為客戶的產品設計空間提供更大的靈活性。

主要特性：
• 內置 GPS 接收器模塊，可為有源天線提供 +5.0 V
• 低功耗（小于 0.6 W），適用于高性能 TCXO溫補晶體振蕩器
• 與傳統 GPS OCXO 參考解決方案相比具有卓越的價格和性能
• 10 MHz CMOS 輸出和 1 pps CMOS 輸出
• 由外部 1 pps 輸入調節
• 調節相位精度達到 75 ns RMS
• GPS NMEA 輸出

應用：
• 低成本參考時鐘
• 測試和測量設備
